The Dunlop Crybaby is a Wah-Wah pedal released around 1982. The pedal is a copy of the original VOX model made by VOX/Thomas Organ Co in 1970. The effect is basically a bandpass filter, it boosts the resonant frequency around 750Hz attenuating above and below harmonics. The rocketing action of the pedal shifts the resonant frequency up and down.Due to the great success of the pedal, being maybe the most sold guitar pedal of all times, Dunlop produced several versions of the Wah-Wah and signature models adding enclosure customization and small circuit modifications. This study is focused on the first model, the Dunlop Crybaby GCB-95 which is considered to have the classic wah tone.Table of Contents.1. The Wah-Wah Effect.The Wah-Wah pedal was invented in November 1966 by Lester Kushner and Brad Plunkett working at Warwick Electronics, a division of Whirlpool that owned Thomas Organ Company and Vox. Thomas Organ patented the Wah circuit design but by the time the patent was granted, there were already dozens of copies of the pedal in the market.

Enforcing the patent was too expensive so no attempt was made to stop the knockoffs.Dunlop started manufacturing the Cry Baby GCB-95 in 1982, copying the original VOX design under license, becoming the most sold pedal of all times. Dunlop Wah-Wahs models are: GCB-95, GCB-95F Classic, GCB-95Q, GCB-535Q, EW-95V, 105Q Bass and 1999 Purple, White, Red or Gray Limited Edition.Signature models include: JH-1 Jimi Hendrix, JH-1FW Jimi Hendrix Fuzz Wah, DB-01 Dimebag Darrel, ZW-45 Zakk Wylde, SC-95/SW-95 Slash Signature, EVH Signature, KH-95 Kirk Hammett, JC-95 Jerry Cantrell, etc.2. The Dunlop Cry Baby GCB-95 Circuit.The Dunlop can be broken down into four blocks: Power Supply, Input Buffer, Active Filter and Output Stage.The circuit is undoubtedly inspired on the. One of the major concerns of the original VOX design was the tone sucking due to the low input impedance of the Input Stage which was 69.5K Ω. Dunlop fixed this problem adding a buffer which raises the input impedance to 1M Ω preserving the guitar original tone. Besides the Input Buffer there are only two changes in the circuit:. R 4 size is reduced (from 510 Ω to 390 Ω): creating a slightly higher voltage gain in the Q 1 stage.

R 8 is also reduced (from 100K Ω to 82K Ω): this change just varies a bit the bias of Q 1, not affecting the tone at all. Prize fighters cody cross. It is just a component resource change.The design is built using 3 cascaded transistor stages with a couple of passive components and an inductor; the simple circuit makes the power consumption below 1mA.The gist of the design remains in how the resonant frequency of an LC filter made up of a fixed inductor L 1 and a fixed capacitor C 2 can be changed using a variable resistor VR 1.Before 1990 all Dunlop Wah pedals had wires between the jacks and the circuit board. In mid-1990 Dunlop changed the PCB design and started mounting the jacks directly on the PCB. Also, from mid-1991 onwards, a buffer circuit was added before the actual wah circuit (it is there if your PCB says ”Rev F” or higher).The current revision looks much like the models that have been running since mid-1992.

For more detailed info about the different versions of the circuit you can check the website.The single layer PCB fits without problems inside the big pedal enclosure using through-hole components.The frequency response is characterized by a resonant peak centered in 750 Hz (with the variable resistor VR 1 at mid position). The peak sweeps up and down from 450 Hz to 1.6 kHz.

Dodo

The selected frequencies are amplified up to 18dB while the surrounding ones are attenuated:The circuit of these 2 pedals is pretty similar; the Dunlop design includes the Input Buffer to preserve the signal integrity but the price (Dunlop slightly cheaper), quality construction and sound are really similar. Players often decide between the two of them just on the looks.Dunlop CryBaby GCB-95 Vs VOX V847 Frequency Response: The crybaby has slightly less bass content. Y ou can check in the graph below how the low freq harmonics are more present in the VOX than in the Dunlop due to the Input Buffer which filters part of this bass content.The most important DC bias points are shown in the image below. It is useful for circuit failure troubleshooting:Q 0 MPSA13Q 1 MPSA18Q 2 MPSA18C in1 0.01uFC in2 22pFC 1 0.01uFC 2 0.01uFC 3 4.7uFC 4 0.22uFC 5 0.22uFC 6 220uFC 7 0.1uFL 1 500mHR in1 2.2M ΩR in2 1.8M ΩR in3 1K ΩR in4 10K ΩR 1 68K ΩR 2 1K5 ΩR 3 22K ΩR 4 390 ΩR 5 470K ΩR 6 470K ΩR 7 33K ΩR 8 82K ΩR 9 1K ΩR 10 10K ΩVR 1 100K ΩInput/Output Jack Connector.True Bypass Switch.3. Power Supply.The simple Power Supply Stage provides a stable energy supply to the circuit.The 9V supply will feed the transistors. The ZL9M3 is a 9.1 zener diode which helps to regulate the power line (protecting the circuit from voltage peaks over 9.1V) and also prevents reverse polarity connections.

Capacitors C 6 and C 7 between 9V and ground remove noise from the power line.4.
